Video on the King Oscillator

A little while ago I wrote a post about the King Oscillator. I’ve decided to prod around a bit more, and what would you know… someone posted a video of it that gives a little more detail. More importantly, it shows how the blade move. Very instructive, if the drawings were not clear enough.

It is a short video – about one cup of coffee – so well worth watching. The same guy also have a video of using the King Oscillator, but I found that less worth watching.

Walter J Smart and the spring loaded safety razor

The safety razor was the cutting edge of shaving technology a hundred and twenty years ago. You could even say the bleeding edge, if your razor featured a replaceable blade that wasn’t quite secure… something Walter J Smart sought to fix with a trio of razor patents.

In chronological order, the patents are British patent 1905-24,010, US patent 881,033, and US patent 960,424. The all revolves around the same idea though; using a spring loaded top cap to pin the blade down. To quite from the earliest of the three, the idea was to:

…provide a razor of this character where in the blade may be easily inserted in its holder and withdrawn therefrom and which will be held accurately in place.

British patent 1905-24,010
Drawings from British patent 1905-24,010
Drawing from US patent 881,033
Drawing from US patent 960,424

As can be seen from the drawings, the basic idea is that a narrow blade is held in place by an arrangement similar in concept to the clothes pins I grew up with. The user would push the rear of the top cap down, insert a blade, and let go of the top cap. To remove the blade, the user would push down the cap and give the razor a shake. All the variations featured blade stops to prevent the blade for sliding too far forward.

I can see this design being easily adapted for most of the narrow single edge blades we use today – the various Feathers, Schick’s Prolines, injector blades… even half a DE-blade would work. And the patents are long expired, so it’s a free for all.

The patents are all available for your reading pleasure at EspaceNet and Google Patents, or alternately over at razors.click:

GB 1905-24,010 (alternate)
US 881,033 (alternate)
US 960,424 (alternate)

Charles Ballreich and the very simple single edge razor

One way to make a profit selling razors in a cut throat market is lowering manufacturing costs. A way to cut cost of manufacture is to have the fewest possible parts, and the fewest possible steps. The easy way to achieve this is to design the razor to be easy to manufacture from the start, rather than trying to modify it later. You can’t get much simpler than one part and – as far as I can estimate – three steps. And that is how simple Charles Ballreich idea for a one piece single edge razor was. It is clear from the patent that ease of manufacture was a a primary objective. To quote from the introduction:

My invention relates to safety razors, and has for its object to provide an exceedingly simple, cheap, and effective safety razor, and to these ends it consists in the various features of construction and arrangement of parts adapted to co-operate in the manner substantially as hereinafter pointed out.

From US patent #855,608
